Application |
Floor scale |
|
Model |
ZHSC03 |
|
Capacity t |
0.5/1/2/3/5/10/20/30/50 |
|
Rated output mV/V |
2.0±0.04 |
|
Accuracy class |
C2 C3 |
|
Maximum number of verification intervals N max |
2000 3000 |
|
Minimum load cell verification intervals V min |
Emax/5000 Emax/7500 |
|
Combined error %RO |
≤±0.030 ≤±0.020 |
|
Creep %RO/30min |
0.02 |
|
Temperature effect on sensitivity %RO/℃ |
0.0016 0.0014 |
|
Temperature effect on zero %RO/℃ |
0.005 0.002 |
|
Zero balance %RO |
±1.0 |
|
Input resistance Ω |
365±10 1050±10(for optional) |
|
Output resistance Ω |
350±3 1000±5( for optional) |
|
Insulation resistance MΩ(50V) |
5000 |
|
Recommended excitation voltage V |
8~15 |
|
Compensated temperature range ℃ |
-10~+40 |
|
Operating temperature range ℃ |
-35~+80 |
|
Safe overload %RO |
150 |
|
Ultimate overload %RO |
200 |
|
Load cell material |
Alloy steel IP67 |
|
Connecting cable |
0.5~3t Φ5.7×3.5m 5~8t Φ5.7×8m 10~50t Φ6.3×13m |
|
Method of connecting wire |
Red input (+) Black input(-) Green output (+) White output(-) |
